臭氧發生器
大型氧氣源臭氧發生器
|
型號 |
額定產量kg/h |
氧氣消耗量Nm3/h |
冷卻水量m3/h |
額定功率KW |
發生器尺寸 L×W×H（mm） |
||
|
120g/Nm3 |
150g/Nm3 |
120g/Nm3 |
150g/Nm3 |
||||
|
NLO-2K |
2.4 |
2 |
20.6 |
13.6 |
3.2 |
15 |
2100×1000×1500 |
|
NLO-3K |
3.6 |
3 |
31.0 |
20.4 |
4.8 |
22.5 |
2500×1500×1800 |
|
NLO-5K |
6 |
5 |
51.6 |
34 |
8 |
37.5 |
2600×1550×2800 |
|
NLO-10K |
12 |
10 |
103.2 |
68 |
16 |
75 |
2750×1650×2100 |
|
NLO-12K |
14.4 |
12 |
123.8 |
81.6 |
19.2 |
90 |
2800×1750×2250 |
|
NLO-20K |
24 |
20 |
206.4 |
136 |
32 |
150 |
2850×1950×2300 |
|
NLO-30K |
36 |
30 |
309.6 |
204 |
48 |
225 |
3050×2600×3070 |
|
NLO-35K |
42 |
35 |
361.2 |
238 |
56 |
262.5 |
3050×2600×3070 |
|
NLO-40K |
48 |
40 |
412.8 |
272 |
64 |
300 |
3050×2600×3170 |
|
NLO-60K |
72 |
60 |
619.2 |
408 |
96 |
450 |
3600×3400×3300 |
|
NLO-80K |
96 |
80 |
825.6 |
544 |
128 |
600 |
3600×3400×3600 |
|
NLO-100K |
120 |
100 |
1032.0 |
680 |
160 |
750 |
3600×3600×4600 |
|
NLO-120K |
144 |
120 |
1238.4 |
816 |
192 |
900 |
3800×4000×5000 |
大型空氣源臭氧發生器
|
型號 |
額定產量kg/h |
空氣消耗量Nm3/h |
冷卻水量m3/h |
額定功率KW |
發生器尺寸 L×W×H（mm） |
||
|
25g/Nm3 |
30g/Nm3 |
25g/Nm3 |
30g/Nm3 |
||||
|
NLO-A-1K |
1.2 |
1 |
41 |
34 |
4 |
16 |
2100×1000×1500 |
|
NLO-A-2.5K |
3 |
2.5 |
102.5 |
85 |
10 |
40 |
2600×1550×2800 |
|
NLO-A-5K |
6 |
5 |
205 |
170 |
20 |
80 |
2750×1650×2100 |
|
NLO-A-6K |
7.2 |
6 |
246 |
204 |
24 |
96 |
2800×1750×2250 |
|
NLO-A-10 |
12 |
10 |
410 |
340 |
40 |
160 |
2850×1950×2300 |
|
NLO-A-15K |
18 |
15 |
615 |
510 |
60 |
240 |
3050×2600×3070 |
|
NLO-A-20K |
24 |
20 |
820 |
680 |
80 |
320 |
3050×2600×3170 |
|
NLO-A-30K |
36 |
30 |
1230 |
1020 |
120 |
480 |
3600×3400×3300 |
|
NLO-A-40K |
48 |
40 |
1640 |
1360 |
160 |
640 |
3600×3400×3600 |
|
NLO-A-50K |
60 |
50 |
2050 |
1700 |
200 |
800 |
3600×3600×4600 |
|
NLO-A-60K |
72 |
60 |
2460 |
2040 |
240 |
960 |
3800×4000×5000 |
